Items suitable for/compatible with
Tecumseh AJ4517Z-HZ3C, CAJ4517Z
CUBIGEL MS26TB
COPELAND CS10K6E-PFV, ZS13KAEPFV818
EMBRACO NJ9238GK
SECOP GS26MLX
TECUMSEH AJ4ZL1HF707A06-M
Tech info
Voltage : 208-220V 1PH 60Hz
Refrigerant : R-404A, R-452A
Horse Power: 1 1/2 HP
| Refrig. Capacity (Btu/h) | |||||||
|---|---|---|---|---|---|---|---|
| Condensing °F | |||||||
| Evap °F | 90 | 95 | 105 | 115 | 120 | 130 | 140 |
| -15 | |||||||
| -5 | 8346 | 7983 | |||||
| 5 | 10673 | 10220 | 9306 | 8382 | |||
| 15 | 13547 | 12988 | 11861 | 10725 | 10153 | 9001 | |
| 25 | 16932 | 16249 | 14877 | 13494 | 12799 | 11403 | 9998 |
| 35 | 20794 | 19970 | 18315 | 16652 | 15817 | 14142 | 12460 |
| 45 | 25098 | 24115 | 22142 | 20162 | 19169 | 17178 | 15183 |
| 55 | 29813 | 28651 | 26321 | 23986 | 22816 | 20472 | 18126 |
