SPECIFICATION
REFRIGERANT R-404A, R-448A, R-449A
Compressor ZF11K4E-PFV
Line Size 1/2” Liquid 7/8" Suction
Refrigerant (Receiver 90%) 15 lbs
Dimensions Fan Data 2 Fan (2936CFM)
38.5(D) x 28.25(W) x 20.75(H)
Net Weight 250 lbs
Power Supply 208-230V 1PH 60HZ3.5HP
Compressor Amp 18.2(RLA), 109.0(LRA)
1 Year Fan Motor and Parts Warranty
