Tech info
Attribute Value
Rating Low Pressure
Reset Auto
Open 10 PSI (.7 Bar)
Close 30 PSI (2.1 Bar)
Tolerance 5 PSI
Burst Pressure 5000 PSI
Temperature Range Ambient -22°F to 176°F (-30°C to 80°C)
Electrical Rating 50/60Hz, 36VDC, 3A
Voltage Amperage 24 125VA pilot duty
Pressure Fittings 1/4” SAE FF
Switch Configuration SPST, OPEN
Lifetime (Cycles) 100,000
Items suitable for/compatible with
P100AP-201C Johnson Control
